IRT ICURE-IR/UV COMBO ROBOTIC

IRT ICURE-IR/UV COMBO ROBOTIC
no-stock
Code: 737413
Brand: IRT Parts
Product Details
IRT ICURE-IR/UV COMBO ROBOTIC


Estimate Freight

To estimate the freight on this item simply enter the destination postcode and the desired quantity and click the "estimate" button.

Postcode

Quantity

IRT ICURE
Robotic, all-inclusive dryer for booth and prep zone

COMPACT ROBOTIC RAIL DRYER
Retrofits to spray booths and prep zones with minor adjustments

IR AND UV CURING
- Save time - ready to handle in minutes
- Reliable, precise curing results

BETTER FOR THE ENVIRONMENT
- Low energy spend per vehicle
- No energy waste in between jobs

BETTER FOR YOU
- Always comfortable booth temperature
- Pre-programmed - easy to operate
- Park in a corner, out of your way

DYNAMIC AND STATIC CURING
- All you need in one unit
- IR and UV curing
- Preprogrammed recipes for both

TWICE AS POWERFUL
- New HID UV lamps
- 2000 W UV lamp in each cassette
- Cures all UV-activated materials on the market

IRT INFRARED
- Original IRT infrared
- Proven cassette concept

MORE FEATURES:
- Robotic motion along the long/short side of the vehicle
- Flexible and easy to move into all positions manually
- Both dynamic and static drying are available
- 2000 W HID UV-A lamps
- Guarded UV safety glass, ozone-free
- Plug and Play, preprogrammed and DIY recipes
- IR lamps > 20.000 hrs, lifetime counter for UV lamps
- IRT shortwave infrared, >97% effective
- Gold coated reflectors determine high efficiency
- Time saving and exact drying process

TECHNICAL SPECIFICATION

- IRT ICure - Art nr 737413
- Nominal frequency - 50-60 Hz
- Rated voltage - 400-480V~3Ph/PE ± 5%
- Full load currency - 26 A
- Main disconnect fuse- 32 A
- Sound pressure / power level - ≤ 70 dB (A) at 1 m
- Ambient temp. (during operation) - Max. 40°C
